Waves are one of the most fundamental concepts in GCSE AQA Physics. 波是GCSE物理中最基础的概念之一，它贯穿了声学、光学和电磁学三大板块。Whether you are preparing for Paper 1 or Paper 2, mastering waves will give you a solid foundation for tackling both calculation and explanation questions. 无论你备考Paper 1还是Paper 2，掌握波动知识都能让你在计算题和解释题中游刃有余。
1. What Is a Wave? 什么是波？
A wave is a disturbance that transfers energy from one place to another without transferring matter. 波是一种传递能量而非物质的扰动。Think of a ripple on a pond: the water molecules oscillate up and down, but they do not travel outward with the ripple. 想象池塘中的涟漪：水分子上下振动，但并不会随着波纹向外移动。
There are two main types of waves you must know for your AQA exam: transverse waves and longitudinal waves. AQA考试要求你掌握两种主要波的类型：横波和纵波。In transverse waves, the oscillations are perpendicular to the direction of energy transfer. 横波中，振动方向与能量传递方向垂直。In longitudinal waves, the oscillations are parallel to the direction of energy transfer. 纵波中，振动方向与能量传递方向平行。
Transverse Waves 横波
Examples: Light, all EM waves, ripples on water, seismic S-waves
例子：光、所有电磁波、水面涟漪、地震S波
Oscillation: perpendicular to energy transfer (90 degree)
振动方向：垂直于能量传递方向
Longitudinal Waves 纵波
Examples: Sound waves, seismic P-waves, ultrasound
例子：声波、地震P波、超声波
Oscillation: parallel to energy transfer
振动方向：平行于能量传递方向
2. Key Wave Properties 波的关键属性
Every wave can be described by four essential properties. 每一个波都可以用四个关键属性来描述。These are the building blocks for every wave calculation you will encounter in your AQA exam. 这些是你AQA考试中所有波动计算的基础模块。
Amplitude 振幅: The maximum displacement from the equilibrium position. Measured in metres (m). 从平衡位置到最大位移的距离，单位为米。The greater the amplitude, the more energy the wave carries. 振幅越大，波携带的能量越多。
Wavelength (lambda) 波长: The distance between two corresponding points on consecutive waves (e.g., crest to crest). Measured in metres (m). 连续波上两个对应点之间的距离（如波峰到波峰），单位为米。
Frequency (f) 频率: The number of complete waves passing a point per second. Measured in hertz (Hz). 每秒通过某一点的完整波的个数，单位为赫兹。1 Hz = 1 wave per second.
Period (T) 周期: The time taken for one complete wave to pass a point. T = 1/f. Measured in seconds (s). 一个完整波通过某点所需的时间，T = 1/f，单位为秒。
3. The Wave Equation 波速公式 v = f lambda
The most important equation in the waves topic is the wave speed equation. 波动章节最重要的公式就是波速公式。You must memorise this for your GCSE exam. 你必须牢记这个公式。
v = f × lambda
Where: v = wave speed (m/s), f = frequency (Hz), lambda = wavelength (m). 其中v是波速（米/秒），f是频率（赫兹），lambda是波长（米）。
Tip: When solving problems, always check your units first. If frequency is given in kHz, convert to Hz by multiplying by 1000. 解题时务必先检查单位。如果频率以kHz给出，先乘以1000转换为Hz。
Example 例题: A wave has a frequency of 50 Hz and a wavelength of 0.4 m. Calculate its speed. 某波频率为50 Hz，波长为0.4 m，计算其波速。
v = 50 × 0.4 = 20 m/s
4. Reflection 反射
Reflection occurs when a wave bounces off a boundary between two media. 当波在两种介质的界面发生反弹时，即为反射。The key rule you need to know is the law of reflection. 你需要掌握的核心规则是反射定律。
Angle of incidence = Angle of reflection (i = r)
入射角等于反射角。Both angles are measured from the normal (an imaginary line perpendicular to the surface). 两个角都从法线（垂直于表面的假想线）开始测量。
Required Practical 必做实验: You must be able to investigate reflection using a ray box, a mirror, and a protractor. 你必须能用光源箱、平面镜和量角器来研究反射。Draw the normal line, measure i and r, and verify they are equal. 画出法线，测量入射角和反射角，验证它们相等。
5. Refraction 折射
Refraction is the change in direction of a wave when it passes from one medium to another due to a change in speed. 折射是波从一种介质进入另一种介质时，因速度改变而发生的方向变化。This is a high-mark topic often tested with ray diagrams. 这是高分常考话题，常以光线图形式出现。
Into a denser medium (e.g. air to glass) 进入更密介质
Wave speed decreases, wavelength decreases, frequency stays the same. 波速减小，波长减小，频率保持不变。
The ray bends towards the normal. 光线向法线方向偏折。
Into a less dense medium (e.g. glass to air) 进入更疏介质
Wave speed increases, wavelength increases, frequency stays the same. 波速增大，波长增大，频率保持不变。
The ray bends away from the normal. 光线远离法线方向偏折。
Key point 关键点: Frequency NEVER changes during refraction because it is determined by the source. 频率在折射过程中永不改变，因为它由波源决定。Only speed and wavelength change. 只有速度和波长会改变。
6. Electromagnetic Spectrum 电磁波谱
All EM waves are transverse and travel at the same speed in a vacuum: 3.0 × 10 to the power of 8 m/s. 所有电磁波都是横波，在真空中以相同速度传播：3.0 × 10的8次方 m/s。You must memorise the order of the EM spectrum. 你必须记住电磁波谱的顺序。
Radio waves 无线电波 → Microwaves 微波 → Infrared 红外线 → Visible light 可见光 → Ultraviolet 紫外线 → X-rays X射线 → Gamma rays 伽马射线
Increasing frequency / decreasing wavelength → 频率递增 / 波长递减
Mnemonic 记忆口诀: Remember "Red Monkeys In Venice Use X-ray Glasses" — Radio, Microwave, Infrared, Visible, Ultraviolet, X-ray, Gamma.
Exam tip 考试技巧: Higher frequency EM waves carry more energy and are more dangerous (ionising). UV, X-rays, and Gamma rays are ionising. 频率越高的电磁波携带的能量越多，越危险（电离性）。紫外线、X射线和伽马射线具有电离性。
7. Sound Waves 声波
Sound waves are longitudinal waves that require a medium to travel through — they cannot travel through a vacuum. 声波是纵波，需要介质才能传播——它们不能在真空中传播。Sound travels fastest in solids, slower in liquids, and slowest in gases. 声波在固体中传播最快，液体中较慢，气体中最慢。
Human hearing range 人耳听觉范围: 20 Hz to 20,000 Hz (20 kHz). Frequencies above 20 kHz are called ultrasound 超声波。Frequencies below 20 Hz are called infrasound 次声波。
Echo sounding / SONAR 回声探测: Ultrasound waves are reflected at boundaries between different media. By measuring the time taken for the echo to return, we can calculate distance: distance = speed × time / 2 (divide by 2 because the sound travels there and back). 超声波在不同介质界面发生反射。通过测量回声返回的时间，可以计算距离：距离 = 速度 × 时间 / 2（除以2是因为声波往返）。
8. Required Practical: Ripple Tank 必做实验：波纹槽
This practical investigates wave properties using a ripple tank. 这个实验使用波纹槽来研究波的属性。You need to measure frequency, wavelength, and wave speed. 你需要测量频率、波长和波速。
Method 方法: (1) Set up the ripple tank with a vibrating dipper. 设置波纹槽和振动棒。(2) Use a strobe light to "freeze" the wave pattern. 使用频闪灯"冻结"波形。(3) Measure wavelength by taking a photo with a ruler in frame. 通过拍摄带标尺的照片来测量波长。(4) Count the number of waves passing a point in 10 seconds to calculate frequency. 数10秒内通过某点的波数来计算频率。(5) Calculate wave speed using v = f × lambda. 使用v = f × lambda计算波速。
Recommended Tool 推荐工具
Wave calculations require precise number crunching. We recommend the Casio fx-991CN X calculator for GCSE Physics — it handles scientific notation, unit conversions, and formula evaluation with ease. 波动计算需要精准的数值运算，推荐Casio fx-991CN X科学计算器——轻松处理科学记数法、单位转换和公式求值。
fx-991CN X 中文版计算器-老王推荐
¥168.00 🛒 微信小店购买Summary Checklist 总结清单
Define transverse and longitudinal waves 定义横波和纵波
Label amplitude, wavelength, crest, trough on a diagram 在图上标注振幅、波长、波峰、波谷
Apply v = f lambda to solve problems 运用v = f lambda解题
State the law of reflection: i = r 陈述反射定律：i = r
Describe refraction in terms of speed change 从速度变化角度描述折射
List the EM spectrum in order of frequency/wavelength 按频率/波长顺序排列电磁波谱
Explain why sound cannot travel through a vacuum 解释为什么声音不能在真空中传播
Describe the ripple tank practical 描述波纹槽实验
Practice Question 练一练
Q: A water wave has a frequency of 5 Hz and a wavelength of 3 m. Calculate the wave speed. A swimmer notices that the wave takes 4 seconds to travel from one end of a 24 m pool to the other. Show that this is consistent with your calculated wave speed. 水波的频率为5 Hz，波长为3 m。计算波速。某游泳者注意到波从24米泳池一端传到另一端需要4秒。验证这与你的波速计算结果一致。
(Hint: First use v = f lambda, then verify using v = distance / time. 提示：先用v = f lambda，再用v = 距离 / 时间验证。)
